Terma Warp Room Vertical Designer Radiator

Please Be Advised: Terma are currently experiencing low levels of stock and lengthy re-stocking periods. We recommend all customers contact our sales line for instant stock levels to avoid disappointment and unforeseen delays – call 01257 452 879 to check Terma stock!

The Terma Warp Room Vertical Designer Radiator uses a tall, double-layered bar arrangement for central heating. A gently curved front layer sits ahead of a flat rear layer between two uprights, creating a shaped surface rather than a plain flat panel. Both models are 1800 mm high, with two widths allowing you to compare the radiator proportions against your available wall space.

• Construction: Double-layered design with curved front bars and a flat rear layer
• Material: Steel
• Sizes: 1800 × 395 mm and 1800 × 525 mm (height × width)
• Finishes: Soft 9016 (Matt White), RAL 5018 (Matt) Teal and Salt n Pepper
• Pipe Centres: 325 mm for the 395 mm-wide model; 455 mm for the 525 mm-wide model
• Wall-to-Pipe-Centre: 65 mm
• Wall-to-Face Depth: 100 mm
• Fuel: Central Heating
• Heating Output: 3870 to 5163 BTU at T50 | 1135 to 1514 W
• Warranty: 8 Year Warranty
• Delivery: 8 to 10 Weeks
• Valves: Not included

Efficiency

The Terma Warp Room Vertical Designer Radiator provides central heating outputs from 3870 to 5163 BTU at T50, with watt outputs from 1135 to 1514 W depending on the selected size. Compare the exact size's output with a heat-loss calculation for your room and the operating temperatures of your heating system.

Contact our sales office for further information: 01257 452 879

Installation

The 395 mm-wide model has pipe centres of 325 mm, while the 525 mm-wide model has pipe centres of 455 mm. Both have a wall-to-pipe-centre measurement of 65 mm and a wall-to-face depth of 100 mm. The manufacturer describes underside connections for the 1800 mm-high models. Where pipework comes through the wall, suitable corner valves are suggested. Check the selected valves and technical drawing before positioning the pipework. Soft 9016 (Matt White) and RAL 5018 (Matt) Teal have smooth matt finishes, while Salt n Pepper has a matt, rough texture. Valves are not included and must be purchased separately.

Check our Radiator Valve Guide for help choosing suitable valves.

Summary

The Terma Warp Room Vertical Designer Radiator combines a distinctive double-layered profile with a tall, modern design. Available in two widths and three finishes, it offers central heating outputs of 3870 to 5163 BTU at T50, an 8 Year Warranty and an 8 to 10 Weeks delivery lead time.
